Kev piav qhia
Hom Lub Npe: ADTECH
Keeb kwm: Shenzhen Tuam Tshoj
Warranty: ib xyoos
Kev them nyiaj yug: online
Qhov kub thiab txias ib puag ncig: 0 ~ 40
Humidity: 90% RH hauv qab
Qhov siab: 1000m, sab hauv tsev, tsawg dua 1000m siab zam plua plav, roj pos huab, thiab roj corrosive
Specification
| servo lub cev muaj zog qauv (ACH) | 0 6050d | 0 6040d | 0 6060 dwb | 0 8075d | 09075d ua | 11060D | 11 120 DC | 11150D | 11180D |
| servo tsav qauv (ACH) | 010M | 020M | 030M | 050M2 | |||||
| Flange specification (mm) | 60 | 60 | 60 | 80 | 86 | 110 | |||
| Rated zog (kW) | 0.2 | 0.4 | 0.6 | 0.75 | 0.75 | 0.6 | 1.2 | 1.5 |
1.8 |
| Rated torque (nm) | 0.64 | 1.27 | 1.91 | 2.4 | 2.4 | 2.0 | 4.0 | 5.0 | 6.0 |
| Qhov siab tshaj plaws torque (nm) | 1.9 | 3.8 | 5.73 | 7.1 | 7.1 | 6.0 | 12 | 15 | 18 |
| ntsuas tam sim no (a) | 1.5 | 2.8 | 3.5 | 4.78 | 3 | 2.5 | 5.0 | 6.0 | 6.0 |
| ntsuas ceev (r / min) | 3000 | ||||||||
| rated tsev (v) | 220 | ||||||||
| inertia (kgm2*10-4) | 0.17 | 0.3 | 0.44 | 1.82 | 2.45 | 3.1 | 5.4 | 6.3 | 7.6 |
| tus lej coder (ppr) | 2500 | ||||||||
| txoj kab uas hla ntawm axes (mm) | 14 | 14 | 14 | 19 | 16 | 19 | 19 | 19 | 19 |
| Qhov ntev ntawm lub cev muaj zog (mm) | 102 | 22 | 144 | 150 | 149 | 159 | 189 | 204 | 219 |
| hnyav (kg) | 1.11 | 1.33 | 1.78 | 2.5 | 3.4 | 4.5 | 5.5 | 6.1 | 6.7 |
FAQ:
1. Dab tsi ntawm servos ADTECH muab?
ADTECH muab ntau hom servo motors, ACH series motors yog cov {{{0}}}.1KW rau 3.8KW motors nrog incremental encoder thiab QX series motors yog 0.1KW rau 3 KW nrog kiag li encoder. Peb kuj muab EtherCAT servo motors kom ua tiav cov kev xav tau siab dua.
2. Hom encoder tau teeb tsa li cas?
Peb muaj ob hom. Ib qho yog incremental encoder thiab lwm tus yog tus encoder kiag li.
3. Dab tsi yog qhov flange loj ntawm ADTCH lub cev muaj zog?
ADTECH muaj ntau qhov ntau thiab tsawg, feem ntau muab faib ua peb hom: low-inertia, nruab nrab-inertia, thiab high-inertia motor. Peb muaj 60mm, 80mm, 110mm, 130mm thiab 180mm flange motors.
Xa, nkoj, thiab kev pabcuam.
Kev xa khoom thiab kev xa khoom: Peb muab kev xa khoom hiav txwv, kev nthuav qhia thoob ntiaj teb, thiab kev thauj mus los hauv huab cua kom xa koj cov khoom rau koj. (Lub sij hawm tuaj txog yuav txawv nyob ntawm lub teb chaws txoj cai thiab kev tsheb khiav.)
