Kev piav qhia
Warranty: ib xyoos
Keeb kwm: Shanghai Tuam Tshoj
Kev them nyiaj yug: online
Hom Lub Npe: STEP
Specification
| Qauv | SIB 6/1400 | SA6/1400H | SIB 8/1800 | |
| Max Ua Haujlwm Radius (MM) | 1405 | 1445 | 1818 | |
| Txoj hauj lwm Repeat Accuracy (MM) | 0.05 | 0.05 | 0.05 | |
| Dab teg Rated PayloadKG) | 6 | 6 | 8 | |
| Degree ntawm kev ywj pheej | 6 | 6 | 6 | |
| Max Ceev (degree / s) | J1 | 180 | 220 | 150 |
| J2 | 180 | 220 | 150 | |
| J3 | 200 | 250 | 160 | |
| J4 | 450 | 430 | 360 | |
| J5 | 320 | 400 | 320 | |
| J6 | 450 | 600 | 360 | |
| Qhov chaw ua haujlwm Max |
J1 (± degree) |
165 | 165 | 165 |
| J2 | 155 degree ~ -90 degree | 155 degree ~ -90 degree | 155 degree ~ -90 degree | |
| J3 | 70 degree ~ -200 degree |
sorting: 70 degree ~ -180 degree vuam: 70 degree ~ -90 degree |
80 degree ~ -190 degree | |
| J4 (± degree) | 170 | 170 | 185 | |
| J5 (± degree) | 120 | 130 | 120 | |
| J6 (± degree) | 360 |
kev: 360 vuam: 220 |
360 | |
| Lub dab teg Allowable Torque | J4 (NM) | 11.8 | 11.8 | 22 |
| J5 (NM) | 9.8 | 9.8 | 16.5 | |
| J6 (NM) | 5.9 | 4.2 | 6.7 | |
| Lub dab teg Allowable Inertia | J4 (kg.㎡) | 0.6 | 0.6 | 0.75 |
| J5 (kg.㎡) | 0.25 | 0.25 | 0.35 | |
| J6 (kg.㎡) | 0.06 | 0.06 | 0.1 | |
| Mounting | hauv av | hauv av | hauv av | |
| kev xav tau | kub (degree) | 0~40 | 0~40 | 0~40 |
| Humidity (%) RH | 45~75 | 45~75 | 45~75 | |
|
Tus nqi vibration ntawm qhov chaw mounting |
hauv qab no 0.5G(4.9M/s2) | hauv qab no 0.5G(4.9M/s2) | hauv qab no 0.5G(4.9M/s2) | |
| Qhov hnyav (KG) | 143 | 165 | 160 | |
