6 Axis High-Performance Motion Control Card Rau Laser Tej Tshuab
Khoom Taw Qhia
ADT-8969 daim npav tswj kev txav yog qhov ua tau zoo 4-axis mem tes servo lub cev muaj zog PCI npav tswj hwm daim npav qhia los ntawm ADTECH. Vim yog ADT-8969 fusion DSP thiab FPGA maub los tsim, ntau yam kev tswj hwm qib siab tuaj yeem hloov tau yooj yim ntxiv, xws li: taw tes-rau-taw tes txav, ntau pawg kev npaj rooj, 2 pawg ntawm {{8} }axis linear interpolation, T / S nkhaus, acceleration/deceleration Tos nws los txhim kho kev ua kis las. Cov qauv no tau nruab nrog lub tsev qiv ntawv txuas dynamic raws li WINDOWS system, uas yooj yim rau kev sau koj tus kheej daim ntawv thov software. Nws kuj muab cov khoom siv nplua nuj thiab cov neeg siv-phooj ywg ADTECH debugging software, uas tuaj yeem kuaj xyuas daim npav tswj hwm thiab lub cev muaj zog tsav yam tsis muaj programming.
Khoom specification
Hom 6 Axis High-Performance Motion Control Card
Tsim nyog lub sij hawm Track motion
Tus qauv npe ADT-8969
Duab puab
Hardware configuration thiab kev ua tau zoo Tus naj npawb ntawm axis 6 axis
Qhov siab tshaj pulse zaus 5M
Tus naj npawb ntawm encoder shafts 6 axis
Encoder tawm tswv yim zaus 4M
Qhov siab tshaj plaws input zaus ntawm tes log 4M
ALM, RDY, INP, SVON √
General digital input 48
Digital tso zis 38
Teeb liab lim √
Hardware nres thaum muaj xwm ceev √
Point tswj Homing tsab ntawv tsa suab √
YOG motion √
Point txav √
S-hom thiab E-hom acceleration thiab deceleration √
Hloov lub hom phiaj txoj hauj lwm nyob rau hauv tsab ntawv tsa suab √
Trajectory tswj Tus lej ntawm pawg tswj hwm pawg 2
Tus naj npawb ntawm cov lus qhia cache 10000 kab lus
2-axes arc interpolation √
3 axes yog interpolation √
Feature
1. A9 dual-core platform, 125us kev qhia lub voj voog, kom ua tau raws li qhov kev ua haujlwm siab-precision khiav du tsim;
2. 5M mem tes zaus, 4M encoder tawm tswv yim zaus, kev lag luam ua lag luam;
3. 10MHz 1D / 2D / 3D high-speed txoj hauj lwm sib piv, 10KHz high-speed txoj hauj lwm latch, txaus los cuam tshuam nrog feem ntau high-precision daim ntaub ntawv;
Cov lus piav qhia txog kev ua tau zoo
1. Ceev foresight thiab cache interpolation:
Kev ceev foresight thiab cache interpolation ntxiv rau ib leeg, thiab lub peev xwm loj cache qhov chaw kom ntseeg tau siab precision thiab siab ceev. Qhov ceev thiab trajectory ntawm ntau ntu ntom ntom interpolation tau txais kev kho kom zoo thiab hloov kho, qhov nrawm yog du, thiab kev co tsis muaj zog, Siab precision ua kom muaj txiaj ntsig zoo.
2. Circular interpolation ceev txwv
Thaum lub cache interpolation tau tsav, lub arc interpolation hauv cache interpolation txheej txheem tuaj yeem teeb tsa ntxiv dawb. Qhov kev txwv ceev ua kom muaj kev hloov pauv ntawm arc interpolation hauv kev kub ceev thiab kev nce qib ntawm kev ceev thiab kev khiav. Kauj ruam tsis siv neeg optimization thiab kho. Kev txwv ceev
tuaj yeem teem tau dawb.
Daim ntawv thov
Lub tshuab engraving, CNC engraving khoom, thiab milling engraving tshuab
