PLMD 60/PLMD+60

STAGE				Qib 2
Kev txo qis	i			15	16	20	25	30		35	40		50	60	70	80	90
Rated tso zis torque	T2N		Nm	55	50	50	60	55		50	45		60	55	50	45	40
			ib. lb	487	443	443	531	487		443	398		531	487	443	398	354
Thaum muaj xwm ceev braking torque Cia 1000 zaug hauv lub neej ua haujlwm ntawm lub gearbox	T2 TSIS		Nm	3 xNOM.Output
			ib. lb
Rated input ceev (T2N, 20 ° C ambient kub)	N 1n		rpm ua	3000	3000	3000	3000		3000	3000	3000		3000	3000	3000	3000	3000
Max input ceev	n 1 max		rpm ua	6000	6000	6000	6000		6000	6000	6000		6000	6000	6000	6000	6000
Maximum rov qab clearance	jt		arcmin	PLWM 60≤5ARCMINPLMD⁺60≤3ARCMIN kev cai ua≤1 ARCMIN
Tsis-load lub sijhawm (nt=3000rmp, gearbox 20 ° C)	T012		Nm	0.4	0.5	0.3	0.5		0.4	0.3	0.3		0.3	0.3	0.4	0.4	0.3
			ib. lb	3.5	4.4	2.7	4.4		3.5	2.7	2.7		2.7	2.7	3.5	3.5	2.7
Torsional rigidity	Ct21		Nm / arcmin	4
			in.lb /arcmin	31
Maximum radial quab yuam	F2 AMAX		N	1600
			lbf ua	360
Maximum axial quab yuam	F3 RMAX		N	400
			lbf ua	90
Qhov siab tshaj plaws yob torque	M2 KMax		Nm	152
			ib. lb	1345
lub neej ncua	Lh		hr	≥20000
Efficiency ntawm tag nrho cov load	η		%	94
Ambient kub	ºC			-15~40
	F			5~40
Qhov siab tshaj plaws tso cai kub ntawm lub plhaub	ºC			+90
	F			194
Lubricating				Lub neej Lubrication
Cov kev taw qhia ntawm kev sib hloov				Input thiab output nyob rau hauv tib txoj kev
Kev tiv thaiv qib				IP65
Kev taw qhia kev teeb tsa				Ib qho
Ua haujlwm nrov (i=10 thiab n1=3000rpm tsis muaj load)	L_PAdB (A)			≤58
Lub sijhawm ntawm inertia	J1	Kg cm²		0.13	0.13	0.13	0.13		0.13	0.13		0.13	0.13	0.13	0.13	0.13	0.13
		10^-3ib lb.s²		0.11	0.11	0.11	0.11		0.11	0.11		0.11	0.11	0.11	0.11	0.11	0.11

Product Description .:

Planetary gearbox yog ib yam ntawm cov reducer nrog dav versatility.
Cov iav sab hauv txais cov pa roj carbon tsawg steel carburizing quenching thiab sib tsoo lossis nitriding txheej txheem.
Planetary gearbox muaj cov yam ntxwv ntawm cov qauv me me, cov zis loj torque, kev kub ceev piv, kev ua haujlwm siab, kev nyab xeeb thiab txhim khu kev qha, thiab lwm yam.
Cov iav sab hauv ntawm lub planetary gearbox tuaj yeem muab faib ua spur iav thiab helical iav.
Cov neeg siv khoom tuaj yeem xaiv qhov raug precision reducer raws li qhov xav tau ntawm daim ntawv thov.

Lub ntsiab nta:

1. High rigidity: Carburizing, carbon nitrogen co-carburizing, ci ntsa iab quenching tshav kub kev kho mob, qhov zoo ntawm high productivity, zoo quenching.
2.High precision: Txais cov cuab yeej siv siab heev, nruj tswj hwm hauv kev ua tau zoo thiab thev naus laus zis.
3.High torque:
(1) Pem hauv ntej plhaub thiab hniav nplhaib txais ib qho qauv tsim
(2) Integrated tsim ntawm planetary ncej thiab tso zis ncej
(3) Bearing ntev span tsim, xyuas kom meej cov zis load peev xwm
(4) Tag nrho rab koob dov, nce kev sib cuag nto
(5) Modular tsim ntawm lub cev muaj zog txuas phaj
4. Tsawg suab nrov:
Lub helical hniav nto yog hloov kho rau cov hniav zoo thiab ua rau kom txo tau qhov cuam tshuam thiab lub suab nrov ntawm iav ntawm cov khoom siv thiab cov khoom tawm,
ces nce iav kev pab lub neej zoo heev.

Nta ntawm SIGRINER Precision planetary gearbox

Lub zog ceev heev, torque nce 40%
Ib qho yooj yim lub cev muaj zog installation, xaiv installation nrog ntev them nyiaj
Kev txhim kho yooj yim, lub gearbox tuaj yeem ntsia tau ntsug, kab rov tav, thiab nce lossis nqis ua ke nrog cov ncej tsav
High positioning precision, rov qab clearance yog tsawg tshaj arc feeb
Los ntawm helical iav meshing, kev ua haujlwm ruaj khov, thiab lub suab nrov khiav tsawg dua 50dB-A
Lub ntiaj teb' lub neej expectancy, thiab cov ntaub ntawv raw thiab mechanism ntawm lub nplhaib foob tau optimized

Kev pab cuam:

Raws li qhov cuam tshuam tsis zoo los ntawm tus neeg siv khoom, SIGRINER engineering software yog siv los tsim cov lus tsa suab load nkhaus daim duab ntawm cov cuab yeej siv tshuab kom tau txais qhov sib thooj tsis sib xws thiab muab cov lus tsa suab load nkhaus. Intuitively tso saib cov tsis tseem ceeb thiab load indexes nyob rau hauv lub kis tau tus mob system los pab cov neeg muas zaub ua raws li cov qauv tsim nyog.
SIGRINER muab amotor database los ntawm 500 servo motor manufacturers thoob ntiaj teb

Kev cob qhia neeg siv khoom:
Peb zoo siab los muab koj nrog peb cov kev siv suav thiab kev tsim kev sib kis. Peb tuaj yeem muab kev cob qhia cuam tshuam raws li koj xav tau. Thov hu rau peb tus engineer, lossis xa acall / wechat rau peb
Daim ntawv thov kev lag luam

Peb muab kev pabcuam sai thiab muaj zog txhawb thoob plaws ntiaj teb los ntawm kev ua tiav kev muag khoom thiab kev pabcuam network
Nrog rau ntau xyoo ntawm kev paub nplua nuj, peb cov kws tshaj lij muaj peev xwm muab kev pabcuam kev pabcuam kev lag luam rau ntau yam kev lag luam
Robotics, automation thiab manipulator technology
Ntau yam ntawm servo gearboxes thiab cov tshuab kis tau tus mob, los ntawm kev lag luam mus rau high-end qauv; tuaj yeem siv rau ntau yam neeg hlau thiab lawv cov axes pabcuam, xws li kis tau tus mob shafts thiab chaw nres tsheb tswj cov cuab yeej
