1. Txhawb rau PLC hom lus, LD, CFC, SFC, FBD, IL, thiab ST.
2. High precision, luv lub sij hawm xam.
3. Muaj ntau database rau algorithm.
4. Kev sib txuas lus huab, kev txheeb xyuas cov ntaub ntawv, khaws cia thiab saib xyuas.
Specification
| Serial | SC20-A3H | SC 20-A3L | |
| Dominant zaus (MHZ) | 480 | 480 | |
| RAM (M) | 32 |
32 |
|
|
FLASH muaj peev xwm (M) |
16 | 16 | |
| Khaws cov ntaub ntawv (K) | 32 | 32 | |
| Qhov voltage (V) | DC 22-28(max 1A) | DC 22-28(max 1A) | |
| Kev qhia lub voj voog (NS) | 2 | 2 | |
Modular qauv |
siab tshaj scalability | 512 | 512 |
| hauv zos scalability | 8 | 8 | |
| tej thaj chaw deb EtherCAT nodes | 16 | 16 | |
| Integration DI/DO/AI | 8 DI, 4DO, 2 AI | 32 DI, 12 DO, 2 AI | |
| Kev tswj xyuas | axis | 20 | 16 |
| mem tes axis | 4 ntxiv 16 (STEP LBUS txuas ntxiv) | 0 ntxiv rau 16 (STEP LBUS txuas ntxiv) | |
| Pib axis kom muaj nuj nqis hauv 1MS | 16 | 16 | |
| linkage interpolation axes | 6 | 6 | |
| Lub sijhawm tsawg kawg ntawm EtherCAT axis (μs) | 120 | 120 | |
| CNC plus PLCOpen | kev txhawb nqa | kev txhawb nqa | |
| Txuas | RS232/RS485/CAN/USB | RS232/RS485/CAN/USB | |
| Muaj tsheb npav |
EtherCAT/Modbus |
EtherCAT/Modbus | |
| Txoj kev sib txuas | module chaw nres nkoj / DIN rail | module chaw nres nkoj / DIN rail | |
| Txoj kev teeb tsa | NID qhia rail | NID qhia rail | |
| Qhov hnyav (KG) | <0.5 | <0.5 | |
| Rated zog (W) | <5 | <5 | |
| Kev siv nyob rau hauv qhov kub thiab txias (degree) | -20~50 | -20~50 | |
| Cia kub (degree) | -20~80 | -20~80 | |
| Tsim nyog cov av noo | 10-90 feem pua ( tsis-condensing ) |
10-90 feem pua ( tsis-condensing ) |
|
| Qhov siab tshaj plaws (KM) | 0-20(tsis muaj kev txwv) | 0-20(tsis muaj kev txwv) | |
| >2KM (txo 5 degree txhua 100M) | >2KM (txo 5 degree txhua 100M) | ||
| Qib ntawm kev tiv thaiv | IP20 | IP20 | |
| Chav kawm ntawm kev ua qias tuaj | IB 33 | IB 33 | |
| Barometric siab (Kpa) | 86-106 | 86-106 | |
| EMC tiv thaiv kev cuam tshuam | EN61000-6-X | EN61000-6-X | |
| Edge xam/Internet ntawm yam | kev txhawb nqa | kev txhawb nqa | |
| software tsim tawm | STEP Automation Studio (Codesy) | STEP Automation Studio (Codesy) | |
Daim ntawv thov
1. 3C, winding tshuab, dispensing tshuab, polishing tshuab.
2. Lithium roj teeb, ntim, khaws, sorting.
3. Tsis yog-tus qauv automation.
4. Lub tshuab nqus dej.
5. Laser teb, txiav, vuam, carving.
6. Semiconductors.
7. Robotic caj npab.
